96-Cavity PCO1881 Mold with Cooling EOAT

96-Cavity PCO1881 Mold with Cooling EOAT

The take-out plate is often the least discussed part of a preform mold package, yet it plays a direct role in how quickly and how consistently preforms can be pulled from a 96-cavity tool. BJY supplies its PCO1881 21.5g preform mold together with a purpose-built take-out plate (EOAT) featuring a multi-stage cooling layout, designed for Husky HyPET series machines rather than adapted from an unrelated cavity count.
Designing the mold and the take-out plate as one system, instead of pairing a mold with a generic third-party EOAT, allows BJY to size the cooling channels, air paths and vacuum layout specifically around the 96-cavity geometry and the 21.5g preform mass being handled.

Consult

Features
Technical Indicators
Overall Dimension

● Take-out plate (EOAT): multi-stage cooling layout, custom-designed to match all 96 cavities rather than retrofitted from another mold.
●Needle valve gate hot runner: individually controlled cavity shut-off, reducing stringing and drooling and supporting consistent gate quality across all 96 cavities.
● Mold base: premium stainless steel with proprietary surface coating for improved release and wear resistance, reducing the mechanical load on the take-out plate during ejection.
● Mold and take-out plate supplied as a matched set, engineered and validated together rather than sourced separately.
● Built for direct compatibility with Husky HyPET series machine platforms.

Applications
Recommended for beverage industry production lines where consistent preform release and stable cooling across every cavity are priorities, particularly at high cavitation counts where a mismatched take-out plate can become the limiting factor on cycle time. Customers are encouraged to share their target cycle time and preform inspection criteria with BJY's technical team so the take-out plate configuration can be reviewed against the specific line before manufacturing.

Why Choose BJY
BJY designs the mold and take-out plate together as a single engineered system, drawing on 20 years of PET packaging mold manufacturing experience and in-house precision CNC production. This integrated approach, supported by pre-sales technical consultation and after-sales commissioning assistance, is intended to reduce the number of variables a customer has to troubleshoot once the tooling is running in production.
Neck Finish PCO1881

Preform Weight 21.5g

Cavity Count 96

Hot Runner Type Needle valve gate

Take-out Plate Cooling Multi-stage cooling

Compatible Machine Platform Husky HyPET series

Base Material Premium stainless steel with surface coating

Neck Finish	PCO1881
Preform Weight	21.5g
Cavity Count	96
Hot Runner Type	Needle valve gate
Take-out Plate Cooling	Multi-stage cooling
Compatible Machine Platform	Husky HyPET series
Base Material	Premium stainless steel with surface coating
